Printer Cartridge Heater
Szczegóły produktu
Opis produktu
Product specification：
Voltage: 12V/24V
Moc: 50W
Heating head size: 6 * 20mm
Heating head material: 304 stainless steel
Line length: 1M and 2M for option
Line thick: 0.5 mm⊃2; (The cross section of the copper wire inside the heater is 0.5mm⊃2;)
Kolor: as shown in the picture
Heating temperature: up to 350 stopnie
Feature of Cartridge Heater :
1. The smallest diameter could be 3 mm.
2. Unlimited length, 15 to 2000mm
3. High power density, and the highest power density could be 50W per square centimeter.
4. Long life time
5. Warranty: One year
6. Different type of wire available according to the usage environment.
| PRODUCT NAME: cartridge heater for pellet stove ignitor heater | |
| SIZE: | DIA 3-50MM* LENGTH 15-3000MM |
| MATERIAL: | SS304/316/321/310S/Incoloy 800 itp. |
| VOLTAGE: | 12-480V |
| POWER: | 10W-3KW |
| SURFACE LOADING: | 2-30W/CM2 |
| THREAD STANARD: | GB/BSP/NPT |
| LEAD WIRE: | 300MM |
| APPLICATION: | WATER, AIR, OIL, MOULD etc. |
