Hot Runner Coil Heater Press In Brass
1.Product Introduction
S.B.T. Hot runner coil heater press in brass are made of nickel chrome resistance wire placed inside chrome nickel steel tube filled with MgO powder and compacted for faster and efficient heat transfer. The integration of temperature thermocouple for the precise temperature control. It also provides the best combination of physical strength, high emissivity and good thermal conductivity to heat hot runner bushings and nozzles.
2. Specyfikacja
 |
Rozmiar: | OD25mm*ID21*L105mm |
| Wire length: | 1meter (Silicone Rubber) | |
| Volts: | 220-240V | |
| Watts: | 750W | |
| Thermocouple sensor: | Termopara typu J. | |
| Minimum Order Quantity: | 3szt | |
| Usage/Application | Moulds & Dies | |
| Materiał grzejnika | Mosiądz |
| Minimum diameter Φ | 10mm |
| Woltaż | 12V- 400V |
| Wattage tolerance | ±10% |
| Tworzywo | SS304/SS321/SS310/SS316 (Dostosowane) |
| Sleeve material | Mosiądz |
| Resistance | ±10% |
| Dielectric strength | 600V 800V 1000V |
| Izolacja(cold 1000V) | ＞10 MΩ |
| Prąd upływowy(cold) | ＜0.5mA |
| Max power density | 10W/cm² |
| Heating length tolerance | ±0.05mm |
| Maximum working temperature allowed on sheath | Max.750℃ / 1380°F |
| Build-in Thermocouple | Type K/ J/ E |
| Standard supply 1000mm PTEE insulated nickel lead wire | |
| Material of lead wire:Fiberglass, Kevlar, Telfon, Silicone Rubber, Metal braided, SUS armoured. | |
3. Szczegóły produktu
| Application examples
Hot runner hearer Plastic industry Packing machine Sprzęt medyczny Casting process Other electric heating industry |
 |
 |
Latest technical process
Superb Heater factory: 1. High density, In addition to filling MgO rod, and also filled high-temperature MgO powder to achieve the optimal density. 2. Have own Tunnel furnace annealing process, focus on high quality product. Other factory: 1. Low density, just filling MgO rod, density is not up to use requirement. 2. Use a simple oven, easy to cause breakage |
| Cechy:
1. Standardowe rozmiary dostępne z różnymi przekrojami |
 |
 |
Korzyść:
1.Niskie MOQ: It can meet your promotional busines-s very well. 2.Zaakceptowano OEM : We can produce any your desig-n as long as you provide us the drawing. 3.Good Service : Traktujemy klientów jak przyjaciół. 4.Good Quality :We have strict quality control syste-m .Good reputation in the foreigner market 5.Szybko & Tania dostawa: We are the manufacturer, have our own factory, direct delivery from the factor-y. |
