Izimfanelo Zomkhiqizo
| uphawu | HOT CORE | Igama Lomkhiqizo | Izinga lokushisa eliphezulu lokuncibilika kwengcindezi |
| Ukucubungula okwenziwe ngendlela oyifisayo | YEBO | imodeli | Idatha ye-PT135C |
| uhlobo | Uhlobo lwesikhombi isilinganiso sokushisa okuphezulu kwe-ncibilikisa ingcindezi | Ibanga lokulinganisa | 0-25MPa/40MPa/70MPa |
| Izinga lokunemba | ±1.0%FS±1.5%FS | Izinga lokushisa le-ambient | 85(℃) |
I-PT135C Series Mechanical Pointer High-Temperature Melt Pressure Gauge/Inzwa Yokucindezela
Isingeniso Somkhiqizo: I-PT135C Series Mechanical Pointer Pressure Gauge (inzwa yokucindezela eyakhelwe ngaphakathi) isetshenziswa kabanzi ekukaleni nasekulawuleni izinga lokushisa eliphezulu lokuncibilika kwengcindezi ku-chemical fiber, uwoyela, ipulasitiki, irabha nezinye izimboni. Lolu chungechunge lwemikhiqizo lusebenzisa umnyakazo ophezulu ongenisiwe ukuze kuqinisekiswe ukunemba kokulinganisa, ukwethembeka okuphezulu, nokusebenza okuhle kakhulu kwe-seismic; igobolondo lensimbi engagqwali eligcwele lihle futhi liqinile, ngokusebenza kokuzamazama komhlaba okuhle kakhulu; futhi ingakhelwa ngaphakathi kwe-strain gauge pressure sensor/transmitter kanye ne-intelligent pressure gauge ukuze kufinyelelwe esilinganisweni esikude nokulawula ingcindezi..
I-PT135C yochungechunge lwesikhombi semishini yokushisa okuphezulu kwezinga lokushisa elincibilikisa izinkomba zokusebenza kwenzwa yokucindezela:
1. Ibanga lokucindezela: 0~25, 40, 70I-MPa;
2. Ukuqonda nqo: mechanical pointer: ±1.5%FS, +2.5%FS;
Inzwa yengcindezi eyakhelwe ngaphakathi kwezinga lokushisa eliphezulu: ±0.5%FS, ±1.0%FS;
3. Ukumelana nezinga lokushisa lokuhlola: 300'℃ (uhlobo lwenduku eqondile)/400'℃ (uhlobo lwepayipi);
4. Ukuxhumana komshini: 1/2″-20UNF, M14x1.5, M22x1.5, G114″, G3/4″ kanye nabanye osayizi bokufaka intambo (ngokuzikhethela);
5. Ukunikezwa kwamandla kwenzwa yokucindezela eyakhelwe ngaphakathi: 10E-DC;
6. Okwakhelwe ngaphakathi kwenzwa yokucindezela: 2.0mVN;
7. Inzwa yokucindezela eyakhelwe ngaphakathi ingafakwa isibonisi sokucindezela kwedijithali: Idatha ye-PS1016, Idatha ye-PT4810, Idatha ye-PS4812, PS8815 uchungechunge kanye PS9016 uchungechunge;
