Coated Tubular Heaters
Coated tubular heaters are custom designed in a various shapes to address client’s requirements for direct immersion in liquids such as water, oils, solvents and process solutions, molten materials as well as air and gases.
Tubular heaters are produced using In colony, stainless steel or Copper sheath materials and also there is huge variety of selection of termination styles available. Insulation of Magnesium offers greater heat transfer.Coated tubular heaters can be used in any application. Straight tubular can be inserted in machined groves for conductive heat transfer and formed tubular provides consistent heat in any type of special application.
Product Description
1.Easy to install, control and maintain
2.For many applications: water, oil, heat transfer fluid, and corrosive solutions, Gas, Steam
3.High power is available, various material
4.Safe and efficient
| Copper Sheath | Water heating, water solutions non-corrosive to copper. |
| Stainless Steel Sheath | Immersion in oils, molten salt baths, alkaline cleaning solutions, tars and asphalt. Also suitable for clamping to metal surfaces and casting into aluminum. Corrosive liquids, food processing equipment. Stainless steel 304 is the normal material. |
| Incoloy Sheath | Air heating, radiant heating, cleaning and degreasing solutions, plating and pickling solutions, corrosive liquids. Usually for high temperature. |
| Titanium tube | corrosive environment. |
Features: Coated Tubular Heaters
1)Liquid-Tight Fittings – 9/16-18 Brass for mounting. Nuts, washers and gaskets included.
2)10-32 Terminals – Stainless steel, complete with nuts and washers.
3)Work Temperatures – See Tubular Heaters overview section for element rated 40 W/In2.
4)Bending – Lengthwise only. See Tubular Heater Overview Section.
Product Type:
Manufacturers: TS heater
Heater Application & Type: Round Cross-Section
Max. Working Temperature: 1600°F
Shape: As per required
Sheath Diameter: 0.430 in.
Sheath Material: Incoloy 316 321 304
Wattage: 2000W Coated Tubular Heaters
