Thick Film Instant Heater For Bathroom
In the bathroom, instant hot water is one of our major needs, so what heating element is suitable? The answer is thick film heaters. The process of making this heating element is that the insulating dielectric material can be printed on the stainless steel substrate in the form of screen printing and sintered at 850°C to produce a high-impedance and high-strength substrate. Its characteristics are similar to PES, but the significant advantage of this type of insulating dielectric material is that it can provide a higher processing temperature and working temperature. The most prominent feature of thick film heaters is instant heating, which cannot be achieved by other heating elements.
Reference specifications:
Electric strength: 1500V/5MA/3S;
Rated voltage: 230V
Insulation resistance: ≥50MS2
Whether to customize: Yes
Product application: dishwasher, electric water heater
Precautions:
1. The temperature rise rate of this type of product is greater than 80°C/S. Make sure that the tube is filled with water before use.
2. When heating the liquid, it must be installed vertically, and the liquid flow direction is from bottom to top to avoid dry burning in local areas.
3. The minimum flow rate should be ensured according to different powers, and the inlet and outlet pipelines should be unblocked to avoid vaporization and dry burning.
4. The product must be grounded reliably.
