Hot Runner Coil Heater
Dettagli del prodotto
1 Introduction for Hot Runner Coil Heater
Hot Runner Coil Heaters are made of nickel chrome resistance wire placed inside chrome nickel steel tube filled with MgO powder and compacted for faster and efficient heat transfer. The heaters are annealed to acquire malleability for bending into any shape. Hot runner heaters with built in thermocouple are also available. Hot runner bushes are produced with hot runner heaters of different cross section with inner brass and outer stainless steel cover.
2 Cross section for Hot Runner Coil Heater
3.0 X 3.0, 3.30 X 3.30, 3.5 X 3.5, 4 X 4 ecc.
4.20 X 2.20, 4.20 X 2.50
Eventuali altre sezioni trasversali possono essere prodotte e fornite su richiesta.
3 Features for Hot Runner Coil Heater
1. Standard sizes available with various cross section
2. Various Watt Density options available.
3. Robust Design with Choice of Terminal Exits
4. Available with built in Thermocouple
5. Designed for even heat profile.
6. Precision fit on Hot Runner Nozzles & Collettori.
7. Highly Non-corrosive.
8. Maximum heat transfer due to more contact area.
9. Advanced Thermal Engineering.
4 Technical specification for Hot Runner Coil Heater
| Sheath Material | Acciaio Cr Ni |
| Materiale isolante | MgO |
| Filo di resistenza | NICR 80-20 |
| Temperatura massima della guaina | 700°C |
| Die forza elettrica | 800V/aria condizionata |
| Isolamento | >5 MW |
| Termocoppia | Tipo J (Standard) o tipo K |
| Tolleranza sulla lunghezza (Dritto) | 5% |
| Tolleranza al ondaggio | + 10% (+ 5% Disponibile su richiesta) |
| Tolleranza alla resistenza | + 10% (+ 5% Disponibile su richiesta) |
| Lunghezza non riscaldata | 35mm (Standard) |
| Tolleranza dimensionale | Bobina ID + 0.1 a 0,2 mm |
| Lunghezza della bobina + 1mm |
5 Application for Hot Runner Coil Heater
1. Ugello per macchina per stampaggio ad iniezione
2. Hot Runner Nozzles & Bushings
3. Macchine per l'imballaggio
4. Hot runner Injection moulds.
5. Injection & Blow Moulding Machine Nozzles.
6. PET prefrom & Thin wall container Moulds
7. Hot runner Manifolds.
