Type J Thermocouple

Type J Thermocouple type J thermocouple Thermocouples are widely used in science and industry; applications include temperature measurement for kilns, gas turbine exhaust, diesel engines, and other industrial processes. Thermocouples are also used in homes, offices and businesses as the temperature sensors in...

Detalles del producto:

Type J Thermocouple

Thermocouples are widely used in science and industry; applications include temperature measurement for kilns, gas turbine exhaust, diesel engines, and other industrial processes. Thermocouples are also used in homes, offices and businesses as the temperature sensors in thermostats, and also as flame sensors in safety devices for gas-powered major appliances.

Item Description
	Tipo	M6 J Type Thermocouple
	Operating Temperature	-40 – 1000 do (-100 – 1800 F)
	Washer Material	Acero inoxidable，Cooper plating with Nickel
	Washer Thickness	1.5 milímetros
	Inner Diameter	12milímetros
	Outer Diameter	16milímetros (1”)
	Cable Length	2M
	Aislamiento	Ungrounded Type
	Cable External Shielding	Stainless Steel Braiding
	Cable Internal Insulation	Fibra de vidrio,CLORURO DE POLIVINILO,teflón
	Connector	Spade Connectors

Características：
1)Design and produce according IEC international standard.
2)fast thermal response time, whole armored configuration, anti-vibración, larga vida útil.
3)kinds of junction box to select to adapt different spaces.
4)Diameter of thermal resistance is φ3~φ8mm,diameter for thermocouple is φ0.5~φ8mm.
5)Convenient to fix for kinds of configurations and fixing methods.
6)Use to measure temperature in different places.
7)Temperature converted circuit available to convert figure measured to simulated figure like 4~20mA, 1~5A in order to be transmitted in long distance.
Thermocouple Wires: Cromel-Alumel, Hierro- Constant, Copper-Constant, imported Bright & Oxidized finish, SWG 10 a 36. PT/PTRH 10%, 13% .
Thermocouple Extension & Compensating Cables: Fiber glass covered, CLORURO DE POLIVINILO / CLORURO DE POLIVINILO. Asbestos / Asbestosis, Teflon/Teflon, Aislado, Teflon/Fg/SS Braided single pair, multi pair, Type K, j, t, R, and PT-100 RTD Cables 2 core, 3 core, 4 core , 6 core, Also Teflon /silicon rubber Teflon/shielded/Teflon etc qualities.
Thermocouple M.I. Cables: SS 316, 310 & Inconel 600 quality type K, j, Simplex 1mm,1.5milímetros, Simplex & Duplex 3mm,6milímetros, 8milímetros, also PT-100 RTD Thermocouple M I Cables SS 316 quality. 3milímetros, 5milímetros, 6milímetros 4 core
Thermocouple Assemblies: Straight, L Type , Rotating type, Inmelt Bolt type, Pencil type, Washer, Holder with Spring. Rotating Type, Adjustable Types etc. Made out of SS tube 4.8mm, 6milímetros,supplied with Spring & Brass bayonets Single Slot & Double Slot , 10mm id, 12mm id, 14mm id, etc..
Solicitud：
1.Plastic injection molding machinery
2.Food processing equipment
3.Engine and turbine exhaust gas
4.Semiconductor processing
5.Heat treating and metals processing
6.Medical equipment
7.Aerospace industries
8.Packaging equipment
9.Test stands

Excellent Material

Featured high quality material. Effectively prevent corrosion and rust,compression explosion-proof.

Tube material:SS304/316,incoloy600 ,incoloy 800 (Se puede personalizar)

Thermocouple Extension & Compensating Cables: Fiber glass covered, CLORURO DE POLIVINILO / CLORURO DE POLIVINILO. Asbestos / Asbestosis, Teflon/Teflon, Aislado, Teflon/Fg/SS Braided single pair, multi pair, Type K, j, t, R, and PT-100 RTD Cables 2 core, 3 core, 4 core , 6 core, Also Teflon /silicon rubber Teflon/shielded/Teflon etc qualities.
