Calentador de bobina espiral de corredor caliente
Detalles del producto
Calentador de bobina espiral de corredor caliente
Hot Runner Spiral Coil Heater is compacted for faster and efficient heat transfer. Generally the long 20-3000mm, spring heating ring external using high quality Ni-Cr steel tube, the internal use of high purity magnesium oxide, high temperature resistance wire. With high working temperature, fast heating, uniform heating precision, larga vida útil, can be automatically controlled area, high thermal conduction, while internal heating material damage, external can be reuses. The heaters are annealed to acquire malleability for bending into any shape. Hot runner heaters with built-in thermocouple are also available.
| Heating section | 2.2×4.2mm 3x3mm 3.4×3.4mm 3.5×3.5m 4x4mm |
| Heating coil ID | 8mm~40mm |
| Heating ring height | 10mm~200mm |
| Voltaje | 15V~380V |
| Wattages | 200W~3000W |
| Build-in thermocouple power | With or without J/K thermocouple |
| Lead wire | 500/1000/1200/1500/2000mm o personalizado |
Available In Cross Section for Hot runner spiral heater:
3.0 x 3.0, 3.30 x 3.30, 3.5 x 3.5, 4 x 4 etc..
4.20 x 2.20, 4.20 x 2.50
Any other cross sections can be csutomized on request.
Application of Hot runner spiral coil heaters:
corredor caliente & Bushings
Tube Extrusion
Pipe Forming
Hot Runner Mould
Plastic Injection Machine
Plastic Extruder Machine
manufacturers and has been focused on the production of industrial heating elements for over 20years, which is well-known as one of the leading manufacturers and suppliers of 1.8mm-35mm or big size cartridge heaters . En los últimos años, Teníamos una sólida reputación por la alta calidad., Rendimiento confiable y gran durabilidad de nuestros productos.. If you are interested in Enail coil heating element. 5pin Enail Coil Heater.Hot Runner Spiral Coil Heater.XLR Plug Spring Coil Heater For Enail.please feel free to contact us.
